JTC30 Coaxial Dual‑Rotor Cleaning Drone — Replace Risky Rope‑Access Work for Higher ROI

29 MPa Ultra‑High Pressure

Generates formidable industrial‑grade power to achieve deep‑penetrating and highly effective surface cleaning performance. The extreme working pressure strips away stubborn dirt, grime and weather‑residue from building exteriors without damaging base materials. It guarantees thorough, professional‑quality surface treatment specifically for skyscraper glass facades, delivering consistent cleaning results even for heavily soiled high‑rise surfaces.

Autonomous Mission Intelligence

Powered by sophisticated autonomous‑mission intelligence, the drone integrates cutting‑edge AI‑driven path‑planning algorithms together with multi‑directional obstacle‑avoidance sensors. These smart capabilities support reliable, hands‑free operation throughout the whole cleaning workflow. Operators only need to confirm mission parameters, and the unit will automatically execute assigned tasks, greatly reducing manual intervention and lowering human‑error risks during complex high‑rise work.

Advanced RTK Autonomy

Built‑in advanced RTK positioning system delivers centimetre‑level positional accuracy in real‑time. Precise geospatial data enables fully autonomous, self‑executing flight missions. The drone can hold stable distances against building walls, follow preset cleaning routes accurately and repeat identical cleaning trajectories across large facade areas. Superior positioning reliability raises overall mission efficiency and improves cleaning uniformity over extensive high‑rise surfaces.

Compact Foldable Design

Adopting a well‑optimised compact foldable mechanical layout, the JTC30 features a highly‑portable main frame. After folding, the unit occupies minimal storage volume. It fits inside ordinary passenger‑vehicle trunks, cutting down expensive special‑logistics and freight costs. Field technicians can complete fast on‑site assembly and deployment within short time windows, helping your cleaning team respond rapidly to different project sites.

Elite Industrial‑Grade Build

Constructed to elite industrial‑grade standards, every core component is selected and validated for continuous heavy‑duty field operation. The whole platform is purpose‑engineered to sustain stable, dependable and secure high‑rise facade‑maintenance work under complex on‑site conditions, including turbulent airflow near tall buildings, temperature fluctuations and long‑hour continuous tethered operation. It stands up to harsh real‑world job‑site demands for long‑term commercial service.
Availability:
Quantity:
  • JTC30 coaxial cleaning drone

  • Joyance

The JTC30 coaxial dual‑rotor drone redefines industrial‑grade facade cleaning with its 8‑motor power configuration and mission‑critical autonomous operation. Fitted with dedicated parallel‑mount nozzles for foam application and high‑pressure water jetting, it supports continuous, non‑stop cleaning cycles without landing.

Powered by a tethered supply system, the JTC30 delivers unlimited runtime for round‑the‑clock operations. Its coaxial rotor architecture maintains stable flight amid turbulent airflow surrounding high‑rise buildings. Rated IPX6, and certified to CE, FCC and RoHS standards, the JTC30 is a safe, high‑ROI exterior‑maintenance solution built for global markets.

Replacing high‑risk rope‑access manual work, the JTC30 achieves 110‑times higher operational efficiency. While conventional human abseiling only reaches roughly 20 m² per hour, this drone covers up to 2,200 m²/h, driven by 4,200 PSI industrial‑grade water pressure.

Fully autonomous with ground‑based operator safety, it eliminates costly scaffolding set‑ups and expensive work‑injury insurance liabilities. Featuring adjustable flow rates from 0‑14 L/min, the JTC30 consistently delivers professional‑quality cleaning finishes for skyscraper facades, maximising B2B return on investment through safe automated technology.


Break free from risky, low‑productivity manual washing. Joyance automated aerial solutions deliver performance 110‑times faster, while guaranteeing full safety for ground‑stationed operators.

In contrast to uneven manual cleaning results, the JTC30 sustains steady industrial‑grade water pressure to preserve building facades without compromising cleaning power. Higher efficiency, enhanced safety and outstanding reliability eliminate long‑standing insurance cost burdens and surface‑damage hazards. Scale up your cleaning business backed by Joyance’s professional aerial‑maintenance standards.

Joyance’s coaxial dual‑rotor design sets a new benchmark for industrial power and flight stability. Featuring counter‑rotating motors on four arms, it achieves 1.8‑times greater thrust density, offering large payload capability within a compact form factor. This mechanical layout counteracts torque for precise yaw control and produces uniform downwash airflow to secure consistent cleaning performance.

Engineered for restricted‑space operations, the JTC30 brings heavy‑duty drone capability to skyscraper exteriors, narrow gaps and balcony zones.


Its integrated dual‑nozzle precision system doubles cleaning efficiency for industrial‑scale projects. Specially engineered parallel assemblies consist of black‑jet foam nozzles and red high‑pressure water nozzles, enabling chemical‑mode switching mid‑mission without landing.

This proprietary non‑landing workflow integrates foam‑softening pre‑treatment and high‑pressure rinsing in a single continuous flight cycle. It solves the frequent industry pain point where foam dries out prior to rinsing. Independently adjustable flow rates adapt to different dirt levels, delivering maximized ROI and consistent dependable performance.


The Joyance JTC30 features an ultra‑compact form factor paired with exceptional agility and portability. Weighing merely 13 kg and folding down to 1,600 mm, it fits easily into standard vehicle trunks to slash transportation costs.

This modular‑built drone performs remarkably well in confined‑space conditions, making it ideal for narrow passages, balconies and indoor factory settings. Supporting single‑person deployment, it allows fast setup with no additional labour required. Its superior close‑proximity manoeuvrability enables precise facade cleaning while operating near building walls.

The JTC30 is your ultimate ROI‑oriented solution for high‑rise cleaning assignments.


The JTC30 coaxial dual‑rotor cleaning drone is equipped with intelligent obstacle‑avoidance radar for advanced environmental perception. Integrated with a 16‑metre high‑precision ranging sensing system, it generates a complete 360° safety bubble to mitigate collision risks during high‑rise missions.

Accurate proximity control sustains consistent cleaning pressure against glass curtain walls, while protecting your valuable equipment investment. Fully aligned with international standards, the JTC30 provides superior safety and reliability for skyscraper cleaning projects.

The JTC30 one‑touch operation control system improves overall efficiency through intuitive on‑board media and spray management. A single tap toggles between water‑spray and foam output, enabling targeted chemical delivery with zero material waste. Fine‑tuned control maximises equipment uptime and substantially cuts operating costs.

Simplifying complex high‑rise maintenance workflows, the JTC30 presents a smarter, more cost‑effective solution for industrial facade cleaning — engineered by Joyance’s expert R&D team.


JTC30 coaxial Cleaning Drone Technical Specifications

Application

Windows/Facade/building/exterial/industrial tank/wind turbine, etc.

Fly
parameters

Fly altitude

Max 280m

Cleaning width

50mm

Cleaning speed

1m/s

Effective distance between nozzle to the building

2-2.5 m

Spray flow

14L/m

Wind resistance

14m/s

Waterproof Level

IP56

Fly time
(battery duration)

Fly height

Fly time

Remaining battery

empty

51 min

25%

30m

42 min

25%

60m

39 min

25%

100m

36 min

25%

150m

30 min

25%

Cleaning efficiency

Windows cleaning

1000~1500 sqm/hour

Facade cleaning

1700~2200 sqm/hour

Configuration

power system

X8*8, IP68

Propeller

3411, carbon fiber

Frame material

50mm carbon fiber, 50mm aviation aluminum alloy

Battery

14S 36000mAh*2, ≥1000 cycles, 6.35kg/pc

Battery charger

3000W,charging time: 30min (30%~95%)

Foam maker

For cleaning detergent

Remote Controller

5.5''screen,1000mAh battery, 6-20 hours

FPV

1080p camera, resolution 1280*720

Water pressure

Electric pump:4100psi (28MPa, 280 bar)
Gasoline pump:3200psi (22MPa, 220 bar) ,7.5HP

Water pipe

160m anti-explosion pipe,16KG,5800PSI,dia: 14mm*8mm

Collission warning

obstacle radar,keep 2m safe distance

Spray boom

steel material,0.5m-1.5m length,0-180°rotation

Spray nozzle

Brass nozzle, 0°, 15°, 25°, 40° adjustment

Weight

Drone weight

13KG(without battery)

25.7KG (with 2 batteries)

Take off weight

55.7kg

Drone Size

Unfold size

W2.25m x L1.87m x H0.49m

Folded size

W1.60m x L0.86m x H0.49m

Wheelbase

1.47m

Packing

Aviation aluminum box

Waterproof and fireproof
